Ultra-Dry 315V Desiccant Dry Cabinet
Model 315V
Ultra-Dry 315V features a spacious interior capacity of 11.8 cu. ft. (334 L) while maintaining a compact footprint.
Model 315V at 11.8 cu. ft. (334 L) is the starter model in Manncorp's larger-volume V series dry boxes.
Although the interior is spacious, 315V's narrow depth (just 18") permits installation in minimal floor space.
Three adjustable shelves and anti-static locking wheels are included.
Prevent Moisture-Related Damage and Failures
Serious defects and failures, including many that don't show up until the product is in the field, can result from improper storage of moisture-sensitive electronic components and assemblies.
Manncorp's V series desiccant cabinets eliminate these failures, along with the risk of moisture-related defects resulting from damaged or improperly resealed moisture barrier bags (MBBs).
Eliminate Ongoing Consumable Expenses
The humidity-controlled cabinets also eliminate the ongoing expense of humidity indicator cards (HICs) and desiccant bags.
Do More With Cabinets
Unlike moisture barrier bags, dry cabinets for electronics components can be used to easily protect loaded tape and stick feeders, partially assembled PCBs, and high-layer-count or class 3 bare boards.
Low-Humidity Environment for Storage
"V" series cabinets use a stand-alone thermo-hygrometer and regenerating desiccant to provide the best possible low-humidity environment for components and assemblies. These cabinets feature two or more turbo modules designed to rapidly reduce RH levels to ≤5% without the use of nitrogen or compressed air.
An RH of ≤5% is significantly lower than specified by IPC/JEDEC J-STD-033C—far more than enough to prevent moisture traces that cause microcracking, popcorning, delamination and solder joint failures.
Nitrogen Environment Available
Nitrogen systems are available as an option.
What If Your Components Have Already Been Exposed to Moisture?
Don't throw them out! Their shelf life can be fully restored using a low-temperature baking cabinet. Ultra Dry model 490H offers similar storage capacity to the 315V with a safe, effective low-temperature bake function added to renew exposed components.
| MODEL | 157V | 290V | 315V | 490V | 790V | 1490V |
|---|---|---|---|---|---|---|
 |
 |
 |
 |
 |
 |
|
| Electrical Requirements | 110V | 110V | 110V | 110V | 110V | 110V |
| External Size L/W/H | 18" x 18" x 38" 450 x 452 x 960 mm |
24" x 27.4" x 25" 600 x 695 x 642 mm |
36" x 18" x 41" 905 x 452 x 1045 mm |
24" x 27.4" x 50" 600 x 695 x 1274 mm |
24" x 27.4" x 72" 600 x 695 x 1820 mm |
47" x 27.4" x 72" 1200 x 695 x 1820 mm |
| Internal Size L/W/H | 18" x 17" x 34" 448 x 425 x 870 mm |
24" x 25" x 21" 598 x 645 x 524 mm |
36" x 17" x 34" 903 x 425 x 870 mm |
24" x 25" x 42" 598 x 645 x 1071 mm |
24" x 25" x 64" 598 x 645 x 1618 mm |
47" x 25" x 64" 1198 x 645 x 1618 mm |
| Capacity | 5.8 cu. ft. (165L) | 7.1 cu. ft. (202L) | 11.8 cu. ft. (334L) | 14.5 cu. ft. (413L) | 22 cu. ft.(624L) | 44.1 cu. ft. (1250L) |
| No. Of Shelves | 3 Adjustable | 2 Adjustable | 3 Adjustable | 3 Adjustable | 5 Adjustable | 5 Adjustable |
| Wheels | N/A | N/A | 2 antistatic, with brakes, 2 standard | 2 antistatic, with brakes, 2 standard | 2 antistatic, with brakes, 2 standard | 2 antistatic, with brakes, 2 standard |
| Power Consumption | Avg 55 w/hr.; Max. 295W | Avg 55 w/hr.; Max. 295W | Avg 105 w/hr.; Max. 585W | Avg 105 w/hr.; Max. 585W | Avg 105 w/hr.; Max. 585W | Avg 105 w/hr.; Max. 585W |
| Shipping Information | 23" L x 23" W x 49" H; 120 lbs | 32" L x 29" W x 34" H; 145 lbs | 23" L x 41" W x 48" H; 200 lbs | 32" L x 29" W x 57" H; 180 lbs | 29" L x 32" W x 79" H; 235 lbs | 32" L x 52" W x 79" H; 445 lbs |
| Humidity Range | ≤5% RH | |||||
| Color | Black | |||||
| Structure | 1 mm thick carbon steel with antistatic paint | |||||
| Door | Compression handles, airtight magnetic sealers and antistatic glass. | |||||
| Grounding Wire | 1MΩ. (940 mm long) | |||||
| ESD Paint | 103~109 Ω. (surface resistance) | |||||
The best performance of the dry cabinet is achieved under the ambient condition of temperature below 30°C and relative humidity below 60% RH.
Use Manncorp Ultra-Dry Storage Cabinets to Protect and Store:
- ICs and components in reels, trays, sticks, feeders or loose in bins or bags prior to placement.
- Multilayer PCBs and bare boards meant for military and other class 3, high-reliability products.
- Double-sided boards that have been partially assembled.
- Moisture-absorbing materials, such as epoxy, resins, chemicals and adhesives.
- Films and plastics used in production.
Performance
A. Start Installation
B. Stable
C. Door Open and Close
Door Is Opened 30 Seconds and Closed
Ultra-Dry "V" series always reaches ≤5%Rh within 30 minutes after the door is opened and closed.
Ultra-Dry 315V includes:
- One black dry cabinet measuring 36" x 18" x 41" (905 mm x 425 mm x 870 mm) LxWxH with 11.8 cu. ft. (334 L) internal capacity
- Two doors with compression handles and airtight magnetic sealers
- Ultra-low humidity storage of ≤5%RH
- 2 Turbo dry modules for faster drying without compressed air
- 2 anti-static wheels with brakes
- 2 standard wheels
- Anti-static paint and glass
- 3 adjustable shelves with 200-lb capacity each
- 1-year warranty
- Digital RH & temperature display
Shipping Information
- Crated Dimensions: Approx. 23" L x 41" W x 48" H (570mm L x 1020mm W x 1220mm H)
- Gross Weight: Approx. 200 lbs. (86 kgs)
